Exoracing Gold and Silver Heat Reflective Sheet 1m x 1.2m

Why Use Gold Or Silver Heat Reflective Sheet?

Radiant heat from turbos, manifolds, downpipes and exhaust systems can quickly heat-soak nearby panels and intake parts. Once an airbox, intake pipe or bulkhead starts absorbing that heat, intake temperatures can rise and nearby components can suffer from repeated heat exposure.

Exoracing heat reflective sheet gives you a large, cut-to-shape barrier that reflects radiant heat before it soaks into the surface underneath. It is especially useful on airboxes, intake ducts, bulkheads, floor panels, seat bases, fuel cells, radiator panels and engine bay covers where a sleeve or wrap would not be the right shape.

The sheet is thin, lightweight and adhesive-backed, so it can be shaped around flat panels and gentle curves without adding unnecessary bulk. It can reflect up to 80% of radiant heat, making it a strong upgrade for fast-road, track, drift and drag cars where engine bay heat management matters.

If the heat source is the turbo itself, reduce heat at the source first with an Exoracing turbo blanket, then use reflective sheet on nearby panels or intake areas. If you need to protect hoses, wiring or lines, use silicone fibreglass heat sleeve or Velcro heat sleeve instead.

Which Exoracing Heat Protection Product Do I Need?

Purchase Includes

• 1 x Exoracing 1m x 1.2m gold or silver heat reflective sheet
• 1 x Exoracing microfibre cloth
• 1 x Exoracing squeegee
• 1 x Exoracing lifetime warranty

Features

• Reflects up to 80% of radiant heat
• Protects panels, bulkheads, airboxes, intake areas and covers
• Helps reduce intake heat soak when applied to intake parts
• Adhesive-backed for quick installation
• Can be cut to shape with scissors or a sharp blade
• Gold or silver reflective foil face
• Lightweight polymer laminated glass cloth construction
• 1m x 1.2m sheet size for larger heat-management jobs
• 450°C continuous temperature rating
• 1100°C intermittent temperature rating
• Includes microfibre and squeegee fitting kit
• Includes Exoracing lifetime warranty

Heat Reflective Sheet Installation Guide

1. Test fit the sheet and mark the area you want to protect.
2. Clean and degrease the surface thoroughly with the supplied microfibre cloth. Isopropyl alcohol is ideal for removing oil, dirt and silicone residue.
3. Make sure the surface is dry, smooth and non-porous before applying the sheet.
4. Cut the sheet to shape using scissors or a sharp blade.
5. Peel back a small section of the backing paper and line up the first edge.
6. Apply firm pressure with the supplied squeegee while slowly removing the backing paper.
7. Work from the centre outwards to reduce trapped air and creases.
8. Check all edges are fully pressed down, especially around curves and corners.

For a full installation walkthrough, use our heat reflective tape and sheet installation guide. For help choosing between sheet, tape, wrap and heat shield products, read our heat shield vs exhaust wrap vs heat tape guide.

Technical Specifications

Frequently Asked Questions

Should I choose gold or silver?

Both options are designed for radiant heat reflection. Choose gold if you want the classic motorsport heat-shield look, or silver if you want a more subtle finish around the engine bay, underbody or interior panels.

What surfaces can I apply it to?

Apply it to clean, dry, smooth, non-porous surfaces such as bare aluminium, stainless steel, painted panels, plastic airboxes and smooth covers. Avoid porous, dirty, oily or heavily textured surfaces, as the adhesive will not bond as well.

Is this better than heat reflective tape?

Use sheet for larger flat areas and cut-to-shape panel work. Use heat reflective tape for smaller areas, narrow sections, pipework or curved pieces where a roll is easier to handle.

Can I use this directly on exhaust parts?

No. Heat reflective sheet is for nearby surfaces that need radiant heat protection. For exhaust manifolds, downpipes or pipework, use Exoracing exhaust wrap.

Does the sheet include fitting tools?

Yes. It includes a microfibre cloth and squeegee to help clean the surface and apply the sheet smoothly.

Notes

• The sheet is rated to 850°F / 450°C continuous and 2000°F / 1100°C intermittent.
• Do not install on porous or contaminated surfaces.
• Clean and degrease the surface before application for the best adhesive bond.
• Use reflective sheet on nearby panels and shields, not directly on exhaust pipes.
